The Revel Ultima2 Series Loudspeakers exemplify subtle elegance with their smooth, rounded shapes, easily blending into a wide variety of décors. Offering an elegant, designer-friendly appearance and unparalleled sound quality, the Revel Salon2 is the highest expression of Revel technology and performance in loudspeaker design and achieves previously unmatched performance. Its sophisticated design even extends to the cast aluminum input and control panel, which is hidden from view yet easily accessible. The smoked access panel continues the elegant shape of the cabinet, even when viewed from the side or rear. The Salon2 is as delightful for the discriminating eye as is satisfying for the refined ear.

Main Features

  • Curvilinear Single Piece Enclosure with 9 Layers of Laminated MDF
  • Narrow Sonically Optimized, 2 ½" Thick Baffle that Virtually Eliminates Diffraction Effects
  • Easily Removable, Magnetically Attached Grilles
  • Pure Beryllium Dome Tweeter with 3rd Generation Waveguide Technology
  • Titanium Cone Woofer and Midrange with Inverted-dome Designs
http://www.revelspeakers.com/Products/Details/42


AWARDS / REVIEWS






Description Ultima2 Loudspeaker Series, 4-Way Floorstanding Loudspeaker
Frequency Response - 3 dB from 23 Hz to 45 kHz ±0.5 dB from 29 Hz to 18 kHz ±1.0 dB from 26 Hz to 20 kHz
Low Frequency Extension -10 dB at 17 Hz -6 dB at 20 Hz -3 dB at 23 Hz
Sensitivity (2.83V @ 1m) 86.4 dB SPL with 2.83 V @ 1m (4 pi anechoic)
Nominal Impedance 6 ohms (nominal) 3.7 ohms (minimum @ 90 Hz)
Crossover Frequencies (Hz) Four-way, high-order acoustic response @150 Hz, 575 Hz, and 2.3 kHz
Ultrahigh-frequency Drive Components 1" (2.5 cm) beryllium tweeter
High-frequency Drive Components 4" (10 cm) titanium cone midrange
Mid-frequency Drive Components 6 ½" (16.5 cm) titanium cone mid-woofer
Low-frequency Drive Components Three 8" (20 cm) titanium cone woofers
Dimensions (H x W x D): 53.3" x 14" x 23" (135.4 cm x 35.6 cm x 58.4 cm)
Weight Weight: 146 lb (66.3 kg) / Shipping weight: 178 lb (80.7 kg)
Finishes Piano black or mahogany finish
